In signaling and interlocking (Panel Interlocking/RRI), the EURRB button is used for Emergency Route Release.

When a route is locked (due to a track circuit failure or a cancelled signal) and the "Route" indicator does not go off, this button is used to release the route manually.

🔘 Important Panel Buttons (AOM/Group B Focus)

As an Operations officer, you must know these functional buttons for the VIVA and Written exam:

Button

Full Form

Purpose

GN

Signal Button

Pressed with the Route Button (UN) to clear a signal.

EURRB

Route Release

Emergency Route Release

UN

Route Button

Defines the entrance/exit of the route.

WWN

Point Group Button

Used with the individual Point Button to operate points.

EWN

Emergency Point Button

Used to operate points when the track circuit is showing "Occupied" (Failure).

EUUYN

Emergency Sub-Route Release

Used for releasing individual sub-routes in a route.

OYN

Calling-on Button

Used with GN to clear a Calling-on signal (for receiving a train on an occupied line).

SM's Key

Station Master's Key

The "Master" control; prevents unauthorized operation when removed.

CHYN

Crank Handle Button

Used to release the Crank Handle for manual point operation.

XYN

Shunt Signal Button

Used to clear a Shunt Signal for shunting operations.

⚠️ Critical Safety Rules for EURRB

  • Counter Increment: Every press of the EURRB (and other emergency buttons) is recorded in a non-resettable counter.

  • Documentation: The SM must record the counter number and the reason for use in the Train Signal Register (TSR) and the Emergency Button Register.

Time Delay: Emergency route release usually has a 120-second (2-minute) time lag to ensure any approaching train has come to a stop.
